DIG-DOG Crawler Scissor Lift |
||||
model |
GSL-06C |
GSL-08C |
GSL-10C |
GSL-12C |
working desk |
2400*1170mm |
2400*1170mm |
2400*1170mm |
2400*1170mm |
Extended table |
900mm |
900mm |
900mm |
900mm |
minimum altitude |
1700mm (without guardrail) |
1820mm (without guardrail) |
1940mm (without guardrail) |
2050mm (without guardrail) |
maximum rise |
8m |
8m |
10m |
12m |
Rated load |
320kg |
320kg |
320kg |
320kg |
Lifting oil pump motor power |
48V/4.0kw |
48V/4.0kw |
48V/4.0kw |
48V/4.0kw |
mobile track |
400mm*2400mm |
350mm*2400mm |
350mm*2400mm |
400mm*2400mm |
platform chassis |
8mm steel plate welding |
8mm steel plate welding |
8mm steel plate welding |
8mm steel plate welding |
Electrical System |
Circuit breakers, intermediate relays, chargers, travel switches, etc. |
Circuit breakers, intermediate relays, chargers, travel switches, etc. |
Circuit breakers, intermediate relays, chargers, travel switches, etc. |
Circuit breakers, intermediate relays, chargers, travel switches, etc. |
way of moving |
Fully automatic walking |
Fully automatic walking |
Fully automatic walking |
Fully automatic walking |
Dimensions |
Length 2700*width 1650*height 1700 (mm) |
Length 2700*width 1650*height 1820 (mm) |
Length 2700*width 1650*height 1940 (mm) |
About length 2700*width 1650*height 2050 (mm) |
Equipment weight |
about 2400kg |
About 2600kg |
About 2800kg |
About 3000kg |
storage battery |
6V200ah*8 pieces |
Fengri maintenance-free 6V*8 |
Chaowei maintenance-free battery |
6V200ah*8 pieces |
